Diesel Generator 15 kVA
Overview of PRODUCT
15 KVA, Three Phase, 415 Volt, 50 Hz, 0.8 P.F.
Power Engineering India Pvt Ltd Make Silent Water Cooled Diesel Generator Set Model No ELG-15N comprising of ESCORTS engine model G15-II. 2 No of Cylinders Engines developing 21.6 HP, Stamford alternator rated at 15 KVA, 415 Volt.
Fuel Consumption at 90% Load = 2.7 Ltr / Hours
GENSET TECHNICAL SPECIFICATION | ||
| Genset Model | ELG-15N | |
| Genset Rating | KVA | 15 |
| Power Factor | PF | 0.8 |
| Genset Rating | kWe | 12 |
| Rated Current AMP | Amps | 21 |
| Engine Rated Power | HP | 21.6 |
| ENGINE TECHNICAL DETAILS | ||
| Engine Model | G15-II | |
| No. of Cylinders | No. | 2 |
| Nature of Aspiration | NA | |
| Displacement | Liters | 1.56 |
| Compression Ratio | 17.5:1 | |
| Bore | MM | 95 |
| Stroke | MM | 110 |
| Electric System | Volt | 12 V DC |
| Lube Oil Consumption | % F. Cons | |
| Lube Oil System Capacity | Liters | 5 |
| Lub. Oil change Period | Hours | 500 Hour or 6 Months |
| Oil Type | Diesel / 15W-40 CI 4 | |
| Governor | Type | Mechanical |
| Battery Capacity | AH | 88 AH |
| ALTERNATOR TECHNICAL DETAILS | ||
| Alternator Model | STAMFORD | |
| Alternator Type | BRUSHLESS | |
| Type of Insulation | Class H | |
| No. of Phase / Voltage | Volt | 230 Volt Single phase or 415 Volt Three Phase |
| Frequency | Hz | 50 Hz |
| CONTROL PANEL | ||
| Control Panel Model | MANUAL (Standard) Panel With DSC Controller DSC4520 | |
| Type of Panel | MANUAL (Standard) / Auto Mains Failure (Optional) | |
| Make of Controller | Deep-sea / Equivalent Reputed make | |
| Location | Mounted Inside Acoustic Enclosure | |
| Type of MCB/MCCB | 3P/4P | 3P MCB |
| Current Breaking Capacity | Amps | 25 |
| ACOUSTIC ENCLOSURE | ||
| Acoustic Enclosure | Outdoor Type, Ready to use – (CPCB-II Complaint) | |
| Noise Level | dB | 75 dB at 1 Meter |
| Emergency Stop | Available, Outside Canopy | |
| Internal Light | Available, Inside Canopy | |
| Fuel Tank Capacity | Liters | 60 Liters |
| Fuel Tank Location | Mounted at base Inside Acoustic Enclosure | |
| Acoustic Enclosure Size in “mm” | L | 1765 |
| W | 900 | |
| H | 1355 | |
| Genset With Weight | Kgs | 700 |
| # Power rating as per standard reference condition as per –BS 5514 / ISO 3046 / ISO 8528/ IS 10002. # All technical specifications are subject to change due to continuous product development without prior notice. # Diesel Generators are manufactured by authorized OEA of ESCORTS LTD. in different design and color. | ||
RS. 6,80,000.00
Code Diesel Generator 15 kVA
Brand ESCORTS
Size 15 kVA
Available Yes
